DeltaOhm HD 2301.0

DeltaOhm HD2301.0 je prijenosni uređaji za merenje relativne vlage i temperature pomoću Pt100 ili termopara, kombinirane sonde za vlagu i temperaturu. Uređaj je opremljenim velikim LCD zaslonom.
Sama temperatura se mjeri uranjanjem, penetracijom, kontaktom i nastrujavanjem (zračna sonda). osjetnici koji se koriste su Pt100 i Pt1000.
Kada je spojena sonda za vlagu/temperaturu uređaj kalkulira i prikazuje apsolutnu vlagu, točku rosišta, djelomični tlak pare, temperaturu mokrog termometra (WBT), omjer miješanja, entalpiju i indekse ugode. Sonda se automatski detektira i dolazi kalibrirana (podaci su spremljeni u samoj sondi)

Tehničke karakteristike

Instrument
Dimenzije
(D x Š x V)                                                                            140x88x38mm
Masa                                                                                     160g (sa baterijama)
Materijali                                                                               ABS
Zaslon                                                                                   2×4½ znamenka + simbol
Vidljiva površina: 52x42mm

Uvjeti okoline
Radna temperatura                                                                -5…+50°C
Temperatura skladištenja                                                       -25…+65°C
Relativna vlaga okoliša                                                           0…90%RV bez kondenzacije
Klasa zaštite                                                                          IP67

Napajanje
Baterije                                                                                 3 x 1.5V tip AA
Autonomija                                                                            200 h sa 1800mAh alkalne baterije
Potrošnja struje uređaj isključen                                              < 20μA

Mjerne jedinice                                                                    °C – °F – %RH – g/m3 – Td – hPa

Konekcije
Ulazni modul za sondu                                                            8-polni muški DIN45326 konektor

Mjerni opseg i točnost UREĐAJA za vlagu
Mjerni opseg                                                                          0…100%RV
Rezolucija                                                                              0.1%RV
Točnost                                                                                 ±0.1%RV
Drift nakon 1 godine                                                               0.1%RV/g.

Mjerni opseg i točnost UREĐAJA za temperaturu
Pt100                                                                                    -200…+650°C
Pt1000                                                                                  -200…+650°C
Rezolucija                                                                              0,1°C
Točnost                                                                                 ±0.1 °C
Drift nakon 1 god.                                                                  0,1°C/god.

Zajedničke karakteristike kombinirane sonde %rH/°C sa SICRAM modulom
Relativna vlaga
Osjetnik                                                                                 Kapacitivni
Mjerni opseg                                                                          0÷100%RV
Drift temperature pri 20°C                                                      Max 0.02%RV/°C
Vrijeme odziva %RV pri
konstantnoj temperaturi                                                         10s (10÷80%RV; brzina zraka=2m/s) pri
konstantnoj temperaturi

Pt100
Drift temperature pri 20°C                                                      0.003%/°C

Termopar tip K – HP572ACR
Drift temperature pri 20°C                                                      0.02%/°C

Zajedničke karakteristike Pt100 sa SICRAM modulom
Drift temperature pri 20°C                                                      0.003%/°C

Zajedničke karakteristike Pt100 (4 žice) i Pt1000 (2 žice)
Drift temperature pri 20°C
Pt100                                                                                    0.003%/°C
Pt1000                                                                                  0.005%/°C
